2-316132-2
TE Connectivity AMP Connectors
2-316132-2
TE Connectivity AMP Connectors
CONN HEADER VERT 5POS 5.08MM
Reference Price (USD)
1+
$1.79672
500+
$1.7787528
1000+
$1.7607856
1500+
$1.7428184
2000+
$1.7248512
2500+
$1.706884
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
2-316132-2
$ 1.80
Product details
Product Attributes
- product status: Active
- connector type: Header
- contact type: Tab
- pitch - mating: 0.200" (5.08mm)
- number of positions: 5
- number of rows: 1
- row spacing - mating: -
- number of positions loaded: All
- style: Board to Board or Cable
- shrouding: Shrouded - 4 Wall
- mounting type: Through Hole
- termination: Solder
- fastening type: Detent Lock
- contact length - mating: -
- contact length - post: 0.150" (3.81mm)
- overall contact length: -
- insulation height: 0.850" (21.59mm)
- contact shape: Rectangular
- contact finish - mating: Gold
- contact finish thickness - mating: 15.0µin (0.38µm)
- contact finish - post: Tin
- contact material: Copper Alloy
- insulation material: Thermoplastic, Polyester, Glass Filled
- features: Board Lock
- operating temperature: -55°C ~ 105°C
- ingress protection: -
- material flammability rating: UL94 V-0
- insulation color: Black
- current rating (amps): -
- voltage rating: 600V
