DF1B-5P-2.5DS(01)
Hirose Electric Co Ltd
DF1B-5P-2.5DS(01)
Hirose Electric Co Ltd
CONN HEADER R/A 5POS 2.5MM
Reference Price (USD)
1+
$0.81000
500+
$0.8019
1000+
$0.7938
1500+
$0.7857
2000+
$0.7776
2500+
$0.7695
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
DF1B-5P-2.5DS(01)
$ 0.81
Product details
Product Attributes
- product status: Active
- connector type: Header
- contact type: Male Pin
- pitch - mating: 0.098" (2.50mm)
- number of positions: 5
- number of rows: 1
- row spacing - mating: -
- number of positions loaded: All
- style: Board to Cable/Wire
- shrouding: Shrouded - 4 Wall
- mounting type: Through Hole, Right Angle
- termination: Solder
- fastening type: Push-Pull
- contact length - mating: 0.177" (4.50mm)
- contact length - post: 0.142" (3.60mm)
- overall contact length: -
- insulation height: 0.224" (5.69mm)
- contact shape: Square
- contact finish - mating: Gold
- contact finish thickness - mating: 8.00µin (0.203µm)
- contact finish - post: -
- contact material: Brass
- insulation material: Polyamide (PA), Nylon
- features: Keying Slot
- operating temperature: -35°C ~ 85°C
- ingress protection: -
- material flammability rating: UL94 V-0
- insulation color: White
- current rating (amps): -
- voltage rating: 250V
