77313-424-22LF
Amphenol ICC (FCI)
77313-424-22LF
Amphenol ICC (FCI)
CONN HEADER VERT 22POS 2.54MM
Reference Price (USD)
1+
$0.65310
500+
$0.646569
1000+
$0.640038
1500+
$0.633507
2000+
$0.626976
2500+
$0.620445
Exquisite packaging
Discount
TT / Paypal / Credit Card / Western Union / Money Gram
77313-424-22LF
$ 0.65
Product details
Product Attributes
- product status: Active
- connector type: Header, Breakaway
- contact type: Male Pin
- pitch - mating: 0.100" (2.54mm)
- number of positions: 22
- number of rows: 2
- row spacing - mating: 0.100" (2.54mm)
- number of positions loaded: All
- style: Board to Board or Cable
- shrouding: Unshrouded
- mounting type: Through Hole
- termination: Solder
- fastening type: Push-Pull
- contact length - mating: 0.266" (6.75mm)
- contact length - post: 0.114" (2.90mm)
- overall contact length: 0.480" (12.19mm)
- insulation height: 0.100" (2.54mm)
- contact shape: Square
- contact finish - mating: Tin
- contact finish thickness - mating: 78.7µin (2.00µm)
- contact finish - post: Tin
- contact material: Phosphor Bronze
- insulation material: Thermoplastic
- features: -
- operating temperature: -65°C ~ 130°C
- ingress protection: -
- material flammability rating: UL94 V-0
- insulation color: Black
- current rating (amps): 3A per Contact
- voltage rating: -
